Building Cables

Building Cables

Building wires are widely used for fixed electrical wiring in residential, commercial, and public buildings. They are commonly installed inside conduits, distribution boxes, walls, ceilings, and electrical equipment. With reliable insulation, easy installation, and good flexibility, they are suitable for lighting, sockets, appliances, and general low-voltage power circuits.
Contact Us

Products Center

Product Details

ModelVoltageProduct Name
60227 IEC 01 (BV)450/750VSingle-core non-sheathed cable with rigid conductor for general purposes
60227 IEC 02 (RV)450/750VSingle-core non-sheathed cable with flexible conductor for general purposes
60227 IEC 05 (BV)300/500VSingle-core non-sheathed cable with solid conductor for internal wiring, conductor temperature 70°C
60227 IEC 06 (RV)300/500VSingle-core non-sheathed cable with flexible conductor for internal wiring, conductor temperature 70°C
60227 IEC 010 (BVV)300/500VLight PVC sheathed cable
60227 IEC 52 (RVV)300/300VLight PVC sheathed flexible cord
60227 IEC 53 (RVV)300/500VOrdinary PVC sheathed flexible cord
BV300/500VPVC insulated cable
BY450/750VPolyethylene insulated cable
BYJ450/750VHeat-resistant 90°C cross-linked polyethylene insulated cable
RYJ450/750VHeat-resistant 90°C cross-linked polyethylene insulated flexible cable
WDZ-BYJ450/750VHeat-resistant 90°C halogen-free low-smoke flame-retardant cross-linked polyolefin insulated cable
WDZ-BYJ(F)450/750VHeat-resistant 90°C halogen-free low-smoke flame-retardant irradiation cross-linked polyolefin insulated cable
WDZ-BYJ-105450/750VHeat-resistant 105°C halogen-free low-smoke flame-retardant cross-linked polyolefin insulated cable
WDZ-BYJ-125450/750VHeat-resistant 125°C halogen-free low-smoke flame-retardant cross-linked polyolefin insulated cable
WDZ-BYJ-150450/750VHeat-resistant 150°C halogen-free low-smoke flame-retardant cross-linked polyolefin insulated cable
BVR450/750VCopper-core PVC insulated flexible cable

ModelVoltageName(The following products are all copper core double-layer co-extruded insulated irradiated AC cables.)
WDZ-GYJS(F)300/500V、450/750Vhalogen-free low-smoke flame-retardant wire
WDZN-GYJS(F)300/500V、450/750Vhalogen-free low-smoke flame-retardant fire-resistant wire
WDZ-GYJSYJ(F)0.6/1kVhalogen-free low-smoke flame-retardant power cable
WDZN-GYJSYJ(F)0.6/1kVhalogen-free low-smoke flame-retardant fire-resistant power cable
WDZ-GYJSYJ(F)230.6/1kVsteel-tape armored halogen-free low-smoke flame-retardant power cable
WDZN-GYJSYJ(F)230.6/1kVsteel-tape armored halogen-free low-smoke flame-retardant fire-resistant power cable
WDZ-GYJSYJ(F)330.6/1kVfine steel-wire armored halogen-free low-smoke flame-retardant power cable
WDZN-GYJSYJ(F)330.6/1kVfine steel-wire armored halogen-free low-smoke flame-retardant fire-resistant power cable
WDZ-GYJSYJ(F)430.6/1kVcoarse steel-wire armored halogen-free low-smoke flame-retardant power cable
WDZN-GYJSYJ(F)430.6/1kVcoarse steel-wire armored halogen-free low-smoke flame-retardant fire-resistant power cable

Product Showcase


Building Cables


Products Center

FAQ

Q: Which countries and regions does your company's service cover?
A:

Our services cover key global regions, including Asia (China, Thailand, Malaysia, etc.), Europe (Germany, France, Italy, etc.), North America (United States, Canada), as well as South Africa, Australia, Brazil, and other regions. We can provide targeted service support according to customer needs.

Q: How long does it take for a customized service to provide an initial solution?
A:

Upon receiving a client's customized request, our professional team will communicate with them within 24 hours to clarify specific requirements (such as technical parameters, scenario adaptation, etc.). A preliminary customized solution can usually be provided within 3-5 business days. For complex requirements, we can negotiate to extend the timeframe and keep the progress in sync.

Q: What is the after-sales response time for overseas projects?
A:

The timeframe varies depending on the region: 24 hours for countries in neighboring Asia, 48 hours for Europe and North America, and 72 hours for other regions such as South Africa and Australia. Special and urgent projects can be expedited upon negotiation.

Q: What is the product warranty period, and what does the warranty cover?
A:

The warranty period for standard products is 1 year, and for core components it can be extended to 2 years (subject to the contract agreement). The warranty covers product quality issues, repairs and replacement of spare parts for malfunctions under normal use, but does not cover damage caused by human error or force majeure.
