Commercial and industrial energy storage systems are designed for factories, shopping centers, office buildings, industrial parks, charging stations, and other high-consumption facilities. They can help reduce peak electricity demand, optimize energy costs, integrate renewable energy, provide backup power, and improve overall power supply stability and efficiency.
Contact Us

Products Center

Product Details

Commerical&Industrial Energy Storage System

ModelYF-ELS24001Y215KYF-ELS26001Y232KYF-ELS24001Y241KYF-ELS26001Y261KRemarks
DC Parameters
Cell TypeLFP-3.2V-280AhLFP-3.2V-314Ah
Rated Battery Energy215kWh232kWh241kWh261kWh
Nominal Voltage768Vdc
(Vlotaghe Range 648V~876V)
832Vdc
(Vlotaghe Range 702V~949V)
768Vdc
(Vlotaghe Range 648V~876V)
832Vdc
(Vlotaghe Range 702V~949V)

Temperature Control MethodSmart liquid cooling/heating50% ethylene glycol, water
AC Parameters(On-Grid)
Rated Power100kW125kW
Grid Voltage400V
Rated Current144A180A
AC Overload Capacity1.1 times forextended periods, 1.2 times for1 minute
Rated Grid Frequency50Hz/60Hz
Cooling MethodAir-cooled
Total Current Harmonic Distortion (THDi)<2.5%(at rated power)<3%(at rated power)
Power factor>0.99 (at rated power)
Power Factor Adjustment Range-1 (leading) to 1 (lagging)
System Parameters
Fire Protection SystemAerosol
Anti-corrosion LevelC3C4 and C5 optional
Ingress ProtectionIP55
Operating Temperature Range-20~55°C
Storage Temperature-20~45°CSOC 30%-50%, <6 months
Operating Humidity Range0~95%RHNo condensation
Installation methodOutdoor installation
System Communication InterfaceEthernet/RS485
External System Communication ProtocolsModbus TCP/Modbus RTU/MQTT
AltitudeUp to 2000m>2000 m (derated)
Dimensions (W×D×H)1000mm*1350mm*2390mm
Weight2500±150kg2600±150kg2500±150kg2600±150kg
Cycle Life≥8000 cycles @0.5C,25±2°C, ≥70%EOL
CertificationsGB/T 36276, IEC 62619, IEC63056, IEC62477, IEC61000,ROHS, UN38.3, MSDS


Products Center

FAQ

Q: Which countries and regions does your company's service cover?
A:

Our services cover key global regions, including Asia (China, Thailand, Malaysia, etc.), Europe (Germany, France, Italy, etc.), North America (United States, Canada), as well as South Africa, Australia, Brazil, and other regions. We can provide targeted service support according to customer needs.

Q: How long does it take for a customized service to provide an initial solution?
A:

Upon receiving a client's customized request, our professional team will communicate with them within 24 hours to clarify specific requirements (such as technical parameters, scenario adaptation, etc.). A preliminary customized solution can usually be provided within 3-5 business days. For complex requirements, we can negotiate to extend the timeframe and keep the progress in sync.

Q: What is the after-sales response time for overseas projects?
A:

The timeframe varies depending on the region: 24 hours for countries in neighboring Asia, 48 hours for Europe and North America, and 72 hours for other regions such as South Africa and Australia. Special and urgent projects can be expedited upon negotiation.

Q: What is the product warranty period, and what does the warranty cover?
A:

The warranty period for standard products is 1 year, and for core components it can be extended to 2 years (subject to the contract agreement). The warranty covers product quality issues, repairs and replacement of spare parts for malfunctions under normal use, but does not cover damage caused by human error or force majeure.
