Containerized Energy Storage System

Containerized Energy Storage System

Containerized energy storage systems provide large-capacity and modular energy storage for utility-scale and industrial projects. They are widely used in solar and wind power stations, grid-side energy storage, microgrids, industrial parks, and remote power systems, supporting renewable energy integration, peak regulation, grid stabilization, and emergency power supply.
Contact Us

Products Center

Product Details

Containerized Energy Storage System:

ModelYF-SLS41606Y2.5MYF-SLS41608Y3.34MYF-SLS41610Y4.18MYF-SLS41612Y5M
Rated Energy2.5MWh3.34MWh4.18MWh5MWh
Dimensions (W×D×H)6058mm*2438mm*2896mm
Weight≈27 Ton≈33 Ton≈38 Ton≈43 Ton
Cell TypeLithium Iron Phosphate(LFP)
Cell Specifications314Ah/3.2V
Rated VoltageDC1331.2V
Operating Voltage RangeDC1123.2V~DC1518.4V
Rated Power1.25MW1.7MW2.15MW2.5MW
Rated Charge/Discharge Current942A/942A1256A/1256A1570A/1570A1884A/1884A
Rated Charge-Discharge Rate0.5C
Energy Efficiency≥92%
Storage Temperature-20~40°C
Operating Temperature-40~60°C
Humidity≤95%, non-condensing
Thermal ManagementLiquid Cooling (50% Ethylene Glycol Solution)
Ingress ProtectionIP55
Fire Protection SystemAerosol/Perfluorohexanone (Optional)
Protection FunctionsShort-circuit, Overcharge/Overdischarge, Over-temperature, Lightning Protection
Fire DetectionYES
Emergency StopYES
UPSYES
CertificationsUN38.3, MSDS, IEC62933, EN61000, IEC62477, IEC62619, IEC63056

Products Center

FAQ

Q: Which countries and regions does your company's service cover?
A:

Our services cover key global regions, including Asia (China, Thailand, Malaysia, etc.), Europe (Germany, France, Italy, etc.), North America (United States, Canada), as well as South Africa, Australia, Brazil, and other regions. We can provide targeted service support according to customer needs.

Q: How long does it take for a customized service to provide an initial solution?
A:

Upon receiving a client's customized request, our professional team will communicate with them within 24 hours to clarify specific requirements (such as technical parameters, scenario adaptation, etc.). A preliminary customized solution can usually be provided within 3-5 business days. For complex requirements, we can negotiate to extend the timeframe and keep the progress in sync.

Q: What is the after-sales response time for overseas projects?
A:

The timeframe varies depending on the region: 24 hours for countries in neighboring Asia, 48 hours for Europe and North America, and 72 hours for other regions such as South Africa and Australia. Special and urgent projects can be expedited upon negotiation.

Q: What is the product warranty period, and what does the warranty cover?
A:

The warranty period for standard products is 1 year, and for core components it can be extended to 2 years (subject to the contract agreement). The warranty covers product quality issues, repairs and replacement of spare parts for malfunctions under normal use, but does not cover damage caused by human error or force majeure.
